Essentials
- Product Collection 8th Generation Intel® Core™ i3 Processors
- Code Name Products formerly Coffee Lake
- Vertical Segment Desktop
- Processor Number i3-8100T
- Lithography 14 nm
CPU Specifications
- Total Cores 4 Total Threads 4
- Processor Base Frequency 3.10 GHz
- Cache 6 MB Intel® Smart Cache
- Bus Speed 8 GT/s
- TDP 35 W
- Configurable TDP-down Base Frequency 2.40 GHz
- Configurable TDP-down 25 W
Supplemental Information
- Marketing Status Launched
- Launch Date Q2’18
- Embedded Options Available Yes
- Use Conditions Embedded Broad Market Commercial Temp, PC/Client/Tablet
- Datasheet View now
Memory Specifications
- Max Memory Size (dependent on memory type) 64 GB
- Memory Types DDR4-2400
- Max # of Memory Channels 2
- Max Memory Bandwidth 37.5 GB/s
- ECC Memory Supported ‡ Yes
GPU Specifications
- GPU Name‡ Intel® UHD Graphics 630
- Graphics Base Frequency 350 MHz
- Graphics Max Dynamic Frequency 1.10 GHz
- Graphics Video Max Memory 64 GB
- Graphics Output eDP/DP/HDMI/DVI
- 4K Support Yes, at 60Hz
- Max Resolution (HDMI)‡ 4096×2304@24Hz
- Max Resolution (DP)‡ 4096×2304@60Hz
- Max Resolution (eDP – Integrated Flat Panel)‡ 4096×2304@60Hz
- DirectX* Support 12
- OpenGL* Support 4.5
- Intel® Quick Sync Video Yes
- Intel® InTru™ 3D Technology Yes
- Intel® Clear Video HD Technology Yes
- Intel® Clear Video Technology Yes
- # of Displays Supported ‡3
- Device ID0x3E91
Expansion Options
- Scalability1S Only
- PCI Express Revision 3.0
- PCI Express Configurations ‡ Up to 1×16, 2×8, 1×8+2×4
- Max # of PCI Express Lanes 16
Advanced Technologies
- Intel® Optane™ Memory Supported ‡ Yes
- Intel® Turbo Boost Technology ‡ No
- Intel® Hyper-Threading Technology ‡ No
- Intel® Transactional Synchronization Extensions No
- Intel® 64 ‡ Yes
- Instruction Set 64-bit
- Instruction Set Extensions Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
- Idle States Yes
- Enhanced Intel SpeedStep® Technology Yes
- Thermal Monitoring Technologies Yes
- Intel® Identity Protection Technology ‡ Yes
Security & Reliability
- Intel® AES New Instructions Yes
- Secure Key Yes
- Intel® Software Guard Extensions (Intel® SGX) Yes with Intel® ME
- Intel® Memory Protection Extensions (Intel® MPX) Yes
- Intel® OS GuardYes
- Intel® Trusted Execution Technology ‡ No
- Execute Disable Bit ‡ Yes
- Intel® Boot Guard Yes
- Intel® Stable IT Platform Program (SIPP) No
- Intel® Virtualization Technology (VT-x) ‡ Yes
- Intel® Virtualization Technology for Directed I/O (VT-d) ‡ Yes
- Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Warranty Information
- Warranty 1 Year
SushovanSushovan –
Good Product
Value for money product. Suitable for Intel LGA1151 6th gen motherboard. It does the work done. Customer service is also good.
