About this item

• High-Resolution 1080p Video: Capture every detail with the 2MP progressive scan CMOS image sensor, offering full HD 1080p resolution for enhanced video clarity.
• Reliable Night Vision: Equipped with Smart IR, the camera ensures clear visibility even in complete darkness, with IR range up to 30 meters.
• Built for All Weather Conditions: IP67-rated weatherproof design guarantees robust performance in harsh weather conditions, making it perfect for both indoor and outdoor installations.
• Advanced Motion Detection: Motion detection with customizable areas ensures optimal surveillance, while the privacy mask protects sensitive areas from unwanted monitoring.
• Easy Setup & Power Options: Choose between DC12V or PoE (Power over Ethernet) for a quick and efficient installation process.
• Secure & Smart Connectivity: With built-in cybersecurity features and support for cloud services, ensure your video feed is safe from unauthorized access.
• Wide Viewing Angle: The 3.6mm fixed lens provides a wide 79° horizontal angle, offering broader coverage for more effective monitoring.
• Mobile Access: Compatible with iPhone, iPad, and Android smartphones, enabling remote viewing and control from anywhere.

Technical Details

• Brand: CP Plus
• Color: White
• Image Sensor: 1/3.2” 2MP PS CMOS Image Sensor
• Minimum Illumination: 0.01 lux @ F2.0 (Color), 0.001 lux @ F2.0 (B/W), 0 lux with IR on
• Effective Pixels: 1920(H) x 1080(V)
• Lens: 3.6mm Fixed-focal Lens
• Mount Type: M12
• Max Aperture: F2.0
• Video Compression: H.265, Smart H.264+, H.264, MJPEG
• Backlight Compensation: BLC, HLC, DWDR
• Video Streaming: Main Stream: 1920 × 1080@(1–25/30 fps), Sub Stream: 704 × 576@(1–25 fps)
• Resolution: 1080p, 1.3MP (1280 × 960), 720p, D1, VGA
• Motion Detection: Customizable detection areas (4 areas, Rectangle)
• Privacy Mask: 4 Areas
• Noise Reduction: 3D-DNR
• S/N Ratio: >56dB
• Bit Rate Control: CBR/VBR
• Protocol: IPv4, IPv6, HTTP, RTSP, RTCP, SMTP, FTP, DHCP, ONVIF (Profile S, Profile T), and more
• Audio: Built-in Mic (G.711a, G.711Mu, G.726, PCM)
• Cybersecurity Features: HTTPS, X.509 Certification, Video Encryption, Trusted Execution, Security Logs
• Smartphone Compatibility: iPhone, iPad, Android
• IR Range: 30 meters (Smart IR)
• Ethernet: RJ-45 (10/100Base-T)
• Power Source: DC12V or PoE
• Power Consumption: 1.2W (Basic), Max. 4W (PoE)
• Weatherproof Rating: IP67
• Operating Temperature: -40°C to +50°C (-40°F to +122°F)
• Storage Temperature: -40°C to +60°C (-40°F to +140°F)
• Dimensions: 198.9 mm × 80.2 mm × 76.2 mm
• Weight: 0.25kg
• Warranty: 1 Year
